Genset Diesel 75 kW 3 Phase
Rp 140.000.000,- ........ Nego !!!!!
YAMAKOYO
Genset Lainnya Genset Diesel 75 kW 3 PhaseRp 140000000  Nego  4Genset Lainnya Genset Diesel 75 kW 3 PhaseRp 140000000  Nego  4Genset Lainnya Genset Diesel 75 kW 3 PhaseRp 140000000  Nego  4
GENSET MODEL YX-75
Rated Power (KW) 75
Max Power (KW) 88
Rated Current (A) 142,4
Rated Voltage (V) 220/380
Frequency (HZ) 50
Rated Speed (RPM) 1500
ENGINE MODEL R6105ZLD
Rated Output (KW) 100
Governing Method MECHANICAL
Bore x Stroke (mm) 105x125
Intaking Method Natural Aspirated
Oil Volume (L) 18
Fuel Consumption 231
Fuel Consumption (L/H) 26,9
Oil Consumption (L/H) 1,63
Displacement L 6,49
Compression ratio 16:1
Water Volume (L) 25
Cooling System Closed water cooled
Starting Method D.C 12V or 24V electric start
ALTERNATOR MODEL UC274C
Power Factor 0,8 lagging for 3-Phase
Phase / Connection 3-Phase 4-Wire connected
Excitation Method Brush/Brushless Excitation
Insulation Class H
Protection Class IP21
Voltage Regulation Automatic
CONTROL SYSTEM DeepSea DSE3110
Dimension and Weight
Net Weight 1250
Dimension (m/ Open type) 2,4 x 0,93 x 1,5
Net Weight 1950
Dimension (m/ SIlent type) 2,75 x 1,1 x 1,55
Engine
Generator
KVA
KW
No. Of Cylinder
Bore x Stroke
Piston Disp
Fuel Consumption
Oil Capacity
:
xmlns:x="urn:schemas-microsoft-com:office:excel"
xmlns="http://www.w3.org/TR/REC-html40">



















style='border-collapse:collapse;table-layout:fixed;width:290pt'>




















































































































































GENSET
MODEL
YX-75
Rated Power (KW) 75
Max Power (KW) 88
Rated Current (A) 142,4
Rated Voltage (V) 220/380
Frequency (HZ) 50
Rated Speed (RPM) 1500
ENGINE MODEL R6105ZLD
Rated Output (KW) 100
Governing Method MECHANICAL
Bore x Stroke (mm) 105x125
Intaking Method Natural Aspirated
Oil Volume (L) 18
Fuel Consumption 231
Fuel Consumption (L/H) 26,9
Oil Consumption (L/H) 1,63
Displacement L 6,49
Compression ratio 16:1
Water Volume (L) 25
Cooling System Closed water cooled
Starting Method D.C 12V or 24V electric start
ALTERNATOR MODEL UC274C
Power Factor 0,8 lagging for 3-Phase
Phase / Connection 3-Phase 4-Wire connected
Excitation Method Brush/Brushless Excitation
Insulation Class H
Protection Class IP21
Voltage Regulation Automatic
CONTROL SYSTEM DeepSea DSE3110
Dimension and Weight
Net Weight 1250
Dimension (m/ Open type) 2,4 x 0,93 x 1,5
Net Weight 1950
Dimension (m/ SIlent
type)
2,75 x 1,1 x 1,55











:
:
:
:
:
:
:
:
Anugrah Diesel kembali menghadirkan Genset Diesel dengan harga terjangkau


Genset Diesel Engine
Merk : Yamakoyo by Anugrah Diesel
Engine : Weifang / Weichai
Alternator : Copy stamford
Daya : 75 kW / 75.000 Watt (Full Load)

Price List ------------- Rp 140.000.000
Hubungi kami untuk mendapatkan harga terbaiknya

- Harga belum termasuk PPN 10%
- Garansi 1 Tahun / 2000 Jam
- Harga dan stock tidak mengikat dan dapat berubah sewaktu-waktu
- Harga franco gudang jakarta
