Genset Diesel 50 kw 3 Phase
Rp 102.500.000,- ........ Nego !!!!!
YAMAKOYO
Genset Lainnya Genset Diesel 50 kw 3 PhaseRp 102500000  Nego  4Genset Lainnya Genset Diesel 50 kw 3 PhaseRp 102500000  Nego  4Genset Lainnya Genset Diesel 50 kw 3 PhaseRp 102500000  Nego  4
GENSET MODEL YX-50
Rated Power (KW) 50
Max Power (KW) 55
Rated Current (A) 95
Rated Voltage (V) 220/380
Frequency (HZ) 50
Rated Speed (RPM) 1500
ENGINE MODEL N4105ZLD
Rated Output (KW) 66
Governing Method MECHANICAL
Bore x Stroke (mm) 105-120
Intaking Method Natural Aspirated
Oil Volume (L) 13
Fuel Consumption 248,8
Fuel Consumption (L/H) 19,1
Oil Consumption (L/H) 2,04
Displacement L 4,15
Compression ratio 17:1
Water Volume (L) 25
Cooling System Closed water cooled
Starting Method D.C 12V or 24V electric start
ALTERNATOR MODEL UC224E
Power Factor 0,8 lagging for 3-Phase
Phase / Connection 3-Phase 4-Wire connected
Excitation Method Brush/Brushless Excitation
Insulation Class H
Protection Class IP21
Voltage Regulation Automatic
CONTROL SYSTEM DeepSea DSE3110
Dimension and Weight
Net Weight 1070
Dimension (m/ Open type) 1,95 x 0,86 x 1,33
Net Weight 1600
Dimension (m/ SIlent type) 2,3 x 1,1 x 1,38
Engine
Generator
KVA
KW
No. Of Cylinder
Bore x Stroke
Piston Disp
Fuel Consumption
Oil Capacity
:
xmlns:x="urn:schemas-microsoft-com:office:excel"
xmlns="http://www.w3.org/TR/REC-html40">



















style='border-collapse:collapse;table-layout:fixed;width:328pt'>




















































































































































GENSET
MODEL
YX-50
Rated Power (KW) 50
Max Power (KW) 55
Rated Current (A) 95
Rated Voltage (V) 220/380
Frequency (HZ) 50
Rated Speed (RPM) 1500
ENGINE MODEL N4105ZLD
Rated Output (KW) 66
Governing Method MECHANICAL
Bore x Stroke (mm) 105-120
Intaking Method Natural Aspirated
Oil Volume (L) 13
Fuel Consumption 248,8
Fuel Consumption (L/H) 19,1
Oil Consumption (L/H) 2,04
Displacement L 4,15
Compression ratio 17:1
Water Volume (L) 25
Cooling System Closed water cooled
Starting Method D.C 12V or 24V electric start
ALTERNATOR MODEL UC224E
Power Factor 0,8 lagging for 3-Phase
Phase / Connection 3-Phase 4-Wire connected
Excitation Method Brush/Brushless Excitation
Insulation Class H
Protection Class IP21
Voltage Regulation Automatic
CONTROL SYSTEM DeepSea DSE3110
Dimension and Weight
Net Weight 1070
Dimension (m/ Open type) 1,95 x 0,86 x 1,33
Net Weight 1600
Dimension (m/ SIlent
type)
2,3 x 1,1 x 1,38











:
:
:
:
:
:
:
:
Anugrah Diesel kembali menghadirkan Genset Diesel dengan harga terjangkau


Genset Diesel Engine
Merk : Yamakoyo by Anugrah Diesel
Engine : Weifang / Weichai
Alternator : Copy stamford
Daya : 50 kW / 50.000 Watt (Full Load)

Price List -------------- Rp 102.500.000
Hubungi kami untuk mendapatkan harga terbaiknya

- Harga belum termasuk PPN 10%
- Garansi 1 Tahun / 2000 Jam
- Harga dan stock tidak mengikat dan dapat berubah sewaktu-waktu
- Harga franco gudang jakarta
