Genset Diesel 15 kw 3 phase
Rp 75.500.000,- ......... Nego !!!!!
YAMAKOYO
Genset Lainnya Genset Diesel 15 kw 3 phaseRp 75500000  Nego  4Genset Lainnya Genset Diesel 15 kw 3 phaseRp 75500000  Nego  4Genset Lainnya Genset Diesel 15 kw 3 phaseRp 75500000  Nego  4
GENSET MODEL YX-15
Rated Power (KW) 15
Max Power (KW) 17
Rated Current (A) 28,5
Rated Voltage (V) 220/380
Frequency (HZ) 50
Rated Speed (RPM) 1500
ENGINE MODEL K4100D
Rated Output (KW) 30,1
Governing Method MECHANICAL
Bore x Stroke (mm) 100*115
Intaking Method Natural Aspirated
Oil Volume (L) 13
Fuel Consumption 248,8
Fuel Consumption (L/H) 8,7
Oil Consumption (L/H) 2,04
Displacement L 4,15
Compression ratio 17:1
Water Volume (L) 25
Cooling System Closed water cooled
Starting Method D.C 12V or 24V electric start
ALTERNATOR MODEL BC184E
Power Factor 0,8 lagging for 3-Phase
Phase / Connection 3-Phase 4-Wire connected
Excitation Method Brush/Brushless Excitation
Insulation Class H
Protection Class IP21
Voltage Regulation Automatic
CONTROL SYSTEM DeepSea DSE3110
Dimension and Weight
Net Weight 680
Dimension (m/ Open type) 1,350 x 0,67 x 1,03
Net Weight 850
Dimension (m/ SIlent type) 1,7 x 0,9 x 1,15
Engine
Generator
KVA
KW
No. Of Cylinder
Bore x Stroke
Piston Disp
Fuel Consumption
Oil Capacity
:
xmlns:x="urn:schemas-microsoft-com:office:excel"
xmlns="http://www.w3.org/TR/REC-html40">








































































































































































GENSET
MODEL
YX-15
Rated Power (KW) 15
Max Power (KW) 17
Rated Current (A) 28,5
Rated Voltage (V) 220/380
Frequency (HZ) 50
Rated Speed (RPM) 1500
ENGINE MODEL K4100D
Rated Output (KW) 30,1
Governing Method MECHANICAL
Bore x Stroke (mm) 100*115
Intaking Method Natural Aspirated
Oil Volume (L) 13
Fuel Consumption 248,8
Fuel Consumption (L/H) 8,7
Oil Consumption (L/H) 2,04
Displacement L 4,15
Compression ratio 17:1
Water Volume (L) 25
Cooling System Closed water cooled
Starting Method D.C 12V or 24V electric start
ALTERNATOR MODEL BC184E
Power Factor 0,8 lagging for 3-Phase
Phase / Connection 3-Phase 4-Wire connected
Excitation Method Brush/Brushless Excitation
Insulation Class H
Protection Class IP21
Voltage Regulation Automatic
CONTROL SYSTEM DeepSea DSE3110
Dimension and Weight
Net Weight 680
Dimension (m/ Open type) 1,350 x 0,67 x 1,03
Net Weight 850
Dimension (m/ SIlent
type)
1,7 x 0,9 x 1,15












:
:
:
:
:
:
:
:
Anugrah Diesel kembali menghadirkan Genset Diesel dengan harga terjangkau


Genset Diesel Engine
Merk : Yamakoyo by Anugrah Diesel
Engine : Weifang / Weichai
Alternator : Copy stamford
Daya : 15 kW / 15.000 Watt (Full Load)

Price List -------------- Rp 75.500.000
Hubungi kami untuk mendapatkan harga terbaiknya

- Harga belum termasuk PPN 10%
- Garansi 1 Tahun / 2000 Jam
- Harga dan stock tidak mengikat dan dapat berubah sewaktu-waktu
- Harga franco gudang jakarta
